Acceleration Datalogger (3 axis) PCE-MSR165
Acceleration, humidity, pressure, temperature and light data logger / 69g weight

The acceleration data logger (3 axis) PCE-MSR165 is a universal and compact logger that measures and stores several physical parameters, especially shocks, oscillations and vibrations. The acceleration data logger (3 axis) PCE-MSR165 is water resistant and it has a 3-axes acceleration sensor (150 microamperes and 13 bits resolution). The acceleration data logger (3 axis) PCE-MSR165 can store 1600 values per second for half a year period. The different values of the acceleration data logger (3 axis) PCE-MSR165 can be sent and visualized through a computer during the measurement or afterwards. With the included software, you can adjust the measuring rate and other parameters. Data from a number of various acceleration data loggers (3 axis) can be divided up synchronously in one file owing to its integrated clock. Transportation, pharmaceutical industry, environment techniques, aviation, research and development, performance sport, mechanical engineering, medical technology, chemicals used in textile industry and many more are typical fields of application for the acceleration data logger (3 axis) PCE-MSR 165. If you have any question about the acceleration data logger (3 axis) PCE-MSR165, please see the technical data below or contact us: +44 (0)2380 987030. Our technicians and engineers will be happy to advise you on the acceleration data logger (3 axis) PCE-MSR165 and on any other product of PCE Instruments regulation and control systems, meters and scales.

Acceleration data logger PCE-MSR165 to measure both impact and vibrations.

- 3 axis acceleration (i.e. to determine position)
- 2,000,000 values memory

- Start/Stop key

- Small dimensions (39 x 23 x 72 mm)

- Optional temperature, relative humidity,

  light and absolute pressure sensors
- Software for the analysis of data in a
  PC or a laptop (included)

- USB interface

- Time and date setting

- Adjustable measurement rate (1600/s ... 12 h)

- Long life accumulator

- LED status indicator (alarm included)

- 67 IP

- Accumulator charge with USB

- 69 g weight

Software for the acceleration data logger

Acceleration data logger PCE-MSR165-software.

Acceleration data logger PCE-MSR165 - graphic.

With the software, you will be able to read and analyse data from different data loggers. The acceleration data logger (3 axes) PCE-MSR165 has a clock  (RTC) for working simultaneously with different data loggers.
Acceleration Dataloggers Technical Specifications

Acceleration

- Measurement Range

- Accuracy

- Measurement Rate


±15 g
±0.15 g (+25 ºC)
up to 1600/s (±15 %)

Optional Sensors

Temperature

- Measurement Range

- Accuracy

- Measurement Rate




-20 ... +65 ºC
-55 - +165ºC (with external sensor)
±0.3 ºC (-10 - +65 ºC)
±2 ºC (with external sensor)
1/s up to 12 h

Relative Humidity with integrated Temperature

- Measurement Range

- Accuracy

- Measurement Rate


0 - 2000 mbar absolute/-20 - +65ºC
± 2.5 mbar (750 - 1100 mbar absolute,
+25 ºC) / ± 0.5 ºC (0 - 65 ºC)
1/s up to 12 h
Optional

- Measurement Range

- Accuracy

- Measurement Rate

From 0 to 14 bar absolute/-20 ... +65 ºC
± 50 mbar (1 ... 10 bar absolute, +25 ºC)/
± 0.5 ºC (0 ... +65 ºC)
1/s up to 12 h
Light

- Measurement Range

- Accuracy

- Measurement Rate


0 - 65.000 lux
Maximum sensibility to 50 mm
1/s up to 12 h

Other Details

Memory More than 2,000,000 values, optionally expandable till 1000 million values with SD card
Start/Finish time  Programmable
Alarm Limit  Free setting
Status Indication Through 3 LEDs
Port USB
Software Included
Power Supply Long life rechargeable lithium polymer battery of 900 mAh (with a USB connection)
Environmental Conditions -20 ... +65 ºC/500 mbar to 2500 absolute
Dimensions 39 x 23 x 72 mm
Weight 69 g
Housing Housing design in anodised aluminum, PC, sealed, waterproof (67IP)
Medium Air, different liquids
Norms EU RoHS/WEEE
Weight 140 g
Uses

Acceleration data logger PCE-MSR165 - image of usage

Delivery content of Acceleration Data Logger
1 x Acceleration Data Logger (3 axis) PCE-MSR165, 1 x software with interface cable, and user manual.
