Ultrasonic Thickness Gauge PCE-TG 300
wide measurement range / up to 600 mm / pulse.eco or echo-echo mode / for all homogeneous materials / print function via bluetooth / USB connection

The PCE-TG 300 is an ultrasonic thickness gauge with special sensors for various applocations. In general, the wall thickness of all homogeneous materials can be measured with the PCE-TG 300. A special sensor is available for damping or scattering materiall like plastics or castings. An angled 90° sensor also allows measurements at measuring points that are difficult to access. The sound velocity of the ultrasonic thickness gauge PCE-TG 300 can be freely adjusted and thus be adapted to different materials.

The easily readable TFT colour display shows the measured values directly. The internal memory which can be read out via the optionally available software allows different measuring spots to be clearly saved. The non-destructive ultrasonic measuring method allows measurements on products which are to be sold to customers. The echo-echo working mode even allows the measurement of coated workpieces.

If you have any further questions about this Ultrasonic Thickness Gauge PCE-TG 300, please ave a look at the folowing technical data or use our contact form or call: UK customers +44(0) 23 809 870 30 / US customers +1-410-387-7703. Our technicians and enigneers will be happy to advise you regarding wall thickness gauges and all other products in the field of regulation and control, laboratory technology, measuring instruments or scales from PCE Instruments.





 go to ultrasonic thickness gauge PCE-TG 300

-wide measuring range

-various sensors availalbe

-battery opration

-fault and cavity detection

-internal data memory

-printing via Bluetooth


Technical specifications of the ultrasonic thickness gauge PCE-TG 300
Measurement ranges

P-E: pulse-echo mode 0.65 ... 600 mm (steel)
E-E: echo-echo mode 2.50 ... 60 mm

Accuracy ±0.04 mm H [mm] (<10 mm); ±0.4 % H [mm] (>10 mm); H refers to the material thickness of the workpiece
Resolution 0.1 mm / 0.01 mm / 0.001 mm (adjustable)
Measurable materials metals, plastics, ceramics, epoxy resin, glass and all homogeneous materials
Operatin modes pulse-echo mode (fault and cavity detection)
echo-echo mode (hiding of coating thicknesses, e. g. varnish)
Calibration sound velocity calibration, zero point calibration, two-point calibration
View mode normal mode, scan mode, difference mode
Units mm / inch
Data transfer printing via BluetoothUSB 2.0
Memory non-volatile memory with 100 data groups, 100 data sets each
Operating time continuous operation 100 h
automatic stand-by mode (adjustable)
automatic power-off mode (adjustable)
Power supply 4 x AA battery 1.5 V
Display 320 x 240 pixel TFT LCD colour display with brightness adjustment
Operating conditions 0 ... +50 °C, ≤80 % RH, non-condensing
Storage conditions -20 ... +70 °C, ≤80 % RH, non-condensing
Dimensions 185 x 97 x 40 mm
Weight 375 g

Specifications of the available sensors for the ultrasonic thickness gauge PCE-TG 300
Model Frequency
[MHz]
Ø
[mm]
Measurement range
[mm]
Minimum pipe diameter
[mm]
Description
NO2 2.5 14 3 ... 300 (steel)
3 ... 40 (cast iron HT200
- (not suitable for curved materials) for damping / scattering materials (plastics, cast)
NO5 5 10 1 ... 600 (steel) Ø20 x 3 normal measurement
NO5/90° 5 10 1 ... 600 (steel) Ø20 x 3 normal measurement
NO7 7 6 0.65 ... 200 (steel) Ø15 x 2 for thin-walled or strongly curved pipes
HT5 5 12 1 ... 600 (steel) 30 for high temperatures (max. 300 °C)
P5EE 5 10 P-E: 2... 600
E-E: 2.5... 100
Ø20 x 3 normal measurement and E-E test


Delivery contents of the ultrasonic thickness gauge PCE-TG 300
1 x ultrasonic thickness gauge PCE-TG 300, 1 x sensor P5EE, 1 x 100 ml coupling gel,
1 x carrying case, 1 x user manual, 4 x AA batteries

Optional accessories








Sensor PCE-TG 300-NO2 (2,5 MHz)
Sensor NO2 for damping / scattering materials (plastics, cast)







Sensor PCE-TG 300-NO5 (5 MHz)
Sensor NO5 for ultrasonic thickness gauge PCE-TG 300







Sensor PCE-TG 300-NO5 / 90° (5 MHz)
Sensor NO5 90° for hard to reach measuring areas








Sensor PCE-TG 300-NO7 (7 MHz)
Sesnor NO7 for thin-walled or strongly curved pipes for the ultrasonic thicknes gauge PCE-TG 300







Sensor PCE-TG 300-HT5 (5 MHz)
hight temperature sensor HT5 of the ultrasonig thickness gauge PCE-TG 300



PC Software with USB cable
(Part no.: PCE-TG 300-SOFT)
Software for data analysis of the PCE-TG 300 ultrasonic thickness gauge






portable bluetooth-printer (power supply, manual)
(Part no.: PCE-TG 300-PRINT)

technical specifications for PCE-TG 250 thickness gauge.
