Vibration Meter PCE-VM 3D
vibration meter PCE-VM 3D for machines and facilities / with internal data storage / analogue interface for head phones / with several sensor tips

The vibration meter PCE-VM 3D provides quick and simple measurements of acceleration, displacements and acceleration speed to check accelerations of machines and construction parts and machines. The vibration meter PCE-VM 3D is able to record vibration in three dimensions on the x-, y- and z- axis. Therefore defects and larger unbalances can be determined. The large display of the vibration meter PCE-VM 3 D allows capturing momentary values as well as recording a whole vibration spectrum. Optionally in addition to this vibration meter there are also additional measuring sensors provided. The large display of the vibration meter PCE-VM 3D features background lights and is well eligible. With its weight of only 305 g the vibration meter PCE-VM 3D proves to be a light accessory at any workplace, whether it is a larger or smaller business, that needs to measure oscillations or larger unbalances on its machines. The determination of errors, defects or larger unbalances can increase the life time of machines and engines significantly. The vibration meter PCE-VM 3D can also be calibrated according to ISO. By checking the oscillation movement of your machines by means of the vibration meter you can also prevent larger damages (by locating the source). In case that you should have more questions regarding the vibration meter PCE-VM 3D, please read the following technical data, use our contact form or call us: UK customers +44(0) 23 809 870 30 / US customers +1-410-387-7703. Our technicians and engineers will gladly advise you regarding the vibration meters or all other products in the field of Control Systems, Laboratory Equipment, Measuring Instruments or Scales and Balances of PCE Instruments Ltd.

 Vibration Meter   User's manual for the Vibration Meter PCE-VM 3D   Vibration Meter PCE-VM 3D   Video of the Vibration Meter PCE-VM 3D   More pictures of the Vibration Meter   Technical specifications  for the Vibration Meter PCE-VM 3D

Vibration Meter PCE-VM 3D

- Measures acceleration and speed
- Measures rotational speed and frequency
- LCD display with background lights
- Large frequency range

- Three options for display
- Common mode
- Spectral mode: shows spectrum
- Bars to show battery state with alarm function

Technical specifications

Measuring ranges

Vibration velocity

0.1 m/s² ... 400.0 m/s² (Peak); (0 ... 40 g force

Vibration acceleration

0.01 ... 400.0 mm/s

Vibration amplitude

0.001 mm ... 4.000 mm (Peak-Peak)

Range of Frequencies:

Vibration velocity

10 Hz ... 10 kHz

Vibration acceleration

10 Hz ... 10 kHz

Vibration amplitude

10 Hz ... 10 kHz

General Specifications:

Resolution 0.25 Hz
Accuracy ±5 %
Interface  RS-232C
Batteries 2 x AA 1.5 V Batteries
Surrounding temperature

0 ... +50 °C / < 95 % rel. error

Dimensions

130 x 70 x 30 mm

Weight

305 g (without batteries)

Vibration meter PCE-VM 3D application
The vibration meter PCE-VM 3D during measurement on an engine

Delivery content:

1 x vibration meter PCE-VM 3D, 1 x cable (1.5 m), 1 x magnetic sensor, 1 x measuring sensor x-, y- and z- axis, 2 x measuring tips, 2 x AA 1.5 batteries, 1 x instruction manual inside hard case

The delivery covers in addition to the vibration meter PCE-VM 3D, also an adequate cable with a measuring sensor in a case that is included in the delivery. To attach those there are also two measuring tips and magnetic sensor included in delivery. The instruction manual is also included.

Vibration meter delivery

Sensor
The standard sensor included in delivery captures values three dimensionally. The vibration meter PCE-VM 3D then determines precisely the relevant values. In order to attach the sensor there are also magnets included in delivery that sticks on any magnetic surface. Even two measuring tips are included in delivery as well as two measuring tips that can be attached to the sensor.

Vibration meter PCE-VM 3 D sensor

Connections
The vibration meter PCE-VM 3D features three connections on the head side. One five-pole sensor input, there the sensor is to attach, one RS-232 interface (2.5 mm) and a head phone connection with 3.5 plugs.

Vibration meter PCE-VM 3 D connections

Calibration certificate
Documentation required for businesses that wish to incorporate the vibration meter into their group of internal control tools or to perform an annual recalibration.  The certificate contains the manufacturer's calibration certification and a test certificate with the measurement values.  The certificate also includes the applicant company's information.

Fourier Synthesis

A periodic signal can be described in terms of a Fourier analysis as a mathematical Fourier series, i.e. the summation of sinusoidal and harmonic partial oscillations. Therefore the periodic functions can be created by overlaying the partial oscillation. For further information follow link.

technical specifications for the vibration level meter PCE-VM 3D. return to homepage
